ALUMINIUM
WINDOWS
LUMIA
The Thermia OC78 LUMIA® series is a high-performance hidden sash casement window.
Its manufacture incorporates an element of asymmetry (central profile) ideal for projects seeking unique design details.
Thermia LUMIA® is a manoeuvrable casement window, however the main sash is not visible from the outside. This creates a sense of integration and visual lightness across the whole facade.
 |  |  |
|---|---|---|
 |  |
LUMIA FEATURES
-
Thermal break: 24 mm
-
Thermal Break
-
Main frame: 70 mm
-
Main leaf: 66 mm
-
Profile thickness: 1.5 mm
-
Maximum glazing width: 30 mm
-
Maximum leaf weight: 160 kg/leaf
-
Available profiles: Window/Balcony Door
-
Canal 16
TEST RESULTS / TRANSMITTANCE
 |  |  |
|---|---|---|
 |  |
CLIMA OPTIMA
The Thermia AR90 CLIMA Series is a casement window with high energy efficiency, ideal for extreme climates and architectural projects where a low Uw value is essential.
In its manufacturing, an asymmetric element (central profile) is incorporated, perfect for projects seeking unique design details. Also Thermia CLIMA is available in two models based on the thermal needs of your project.
Thermia CLIMA’s sash design provides a space wide enough to house triple glazing.This means triple smart glass can be used in combination with multiple sheets to increase insulation inside homes.
CLIMA OPTIMA FEATURES
-
Thermal break (frame): 42 mm (Thermia CLIMA COMPLETE with injected foam)
-
Thermal break (leaf): 42 mm (Thermia CLIMA COMPLETE with injected foam)
-
Main frame: 82 mm
-
Main leaf: 90 mm
-
Profile thickness: 1.5 mm
-
Maximum glazing width: 52 mm
-
Maximum leaf weight: 160 kg/leaf
-
Available profiles: Window/Balcony Door
-
Hardware: Tilted windows / Casement windows / Sliding window ( both options: Thermia CLIMA COMPLETE and Thermia CLIMA OPTIMUM )
TEST RESULTS / TRANSMITTANCE
AR78+ HABITAT CE FEATURES
-
Thermal break: YES/24 mm
-
Main frame: 70 mm
-
Main leaf: 78 mm
-
Profile thickness: 1.5–1.8 mm
-
Maximum glass thickness: 53 mm
-
Max. weight of casement leaf 90 Kg
-
Max. weight of tilt leaf: 130 Kg
-
Available profiles: Door or Window
TEST RESULTS / TRANSMITTANCE
HABITAT
The Thermia AR78+ CE HABITAT series is a system for windows and doors with exceptional technical features, offering extremely high thermal and acoustic insulation.
Solutions are available for different types of doors and windows. Furthermore, all of its profiles are suitable for two-colour projects and/or curved windows.
 |  |  |
|---|
